The AdderLink AV Series ALAV104T transmitter delivers high video resolutions and quality audio up to 300m/1000 feet using standard CATx cable (x=5,5e,6,7). Designed for use in Digital Signage applications, the design of this extender allows for flexible distribution that can grow in line with project developments and ensures direct delivery of crystal clear communication to consumers at the point of decision.
Adder AV-Series KVM Extender System Diagram
Adder ALAV104T Features
- Extends a single high-resolution video and high fidelity audio signal to 4 different receivers
- Local port to connect local screen and speakers or to cascade to other AdderLink AV 104T transmitter units
- Extends video and audio across a single CATx cable
- Extra fine video quality at resolutions up to 1600 x 1200 at 200m and 1280 x 1024 at 300m
- High fidelity click less digital audio (16bit, 44.1 kHz, stereo)
- Independent sharpness and brightness control
- DDC support
- Feed through / cascade port at transmitter
- Dual video and audio outputs at receiver
- Use stand alone or rack mount 16 modules across 3U
- Advanced spike suppression circuits for reliability in ‘noisy’ installations
- All metal construction
- Power / video indication confirm correct operation
- Adjustable cable equalization amplifiers
- Audio transmitted as digital signals to ensure high fidelity and low noise levels
Technical Specifications
| Video | Analog VGA/AV over CATx |
| Extension | Up to 100m over CATx |
| Audio | Included |
| Serial | RS232 (200 series); optional on 100 series |
| OS Support | All known operating systems |
Source: Adder Technology — ADDERLink AV100. Verify with manufacturer.
