SML Smart Locks & Security
SML-KIT-SCO-60-2D
(2) H3-EM-60-100 Electronic Swinghandle - High security DIN lock - (1) DX2-DH2C2 Intelligent Door Sensor - Two active dry contacts powered by 12V to support 3rd party door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors- (2) 4 meter lock connector cables included.
SML-KIT-SCO-66-2D
(2)Electronic Handles H3-EM-66-100 - 13.56 MHz MIFARE? Classic 4k MIFARE Plus? 2k MIFARE? DESFire? 4k & iClass UID/integrated card reader: supports ISO14443 A [13,56 MHz] card types - Wiegand Output protocol - 4 pin reader connector - (1) DX2-DH2C2 Intelligent Door Sensor with Two active dry contacts powered by 12V to support (2) door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors - (2) 4 meter lock connector cables included.
SML-KIT-SCO-67-2D
(2)Electronic Handles H3-EM-67-100 - 13.56 MHz MIFARE? Classic 4k MIFARE Plus? 2k MIFARE? DESFire? 4k /integrated card reader: supports ISO14443 A [13,56 MHz] card types - Wiegand Output protocol - 4 pin reader connector - (1) DX2-DH2C2 Intelligent Door Sensor with Two active dry contacts powered by 12V to support (2) door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors - (2) 4 meter lock connector cables included.
SML-KIT-SCO-68-2D
(2) H3-EM-68-100 Electronic Swinghandle and RFID Card Reader - 125 kHz Prox card reader - supports HID 125 kHz Prox card types - Wiegand Output protocol - 4 pin reader connector- High security DIN lock (1) DX2-DH2C2 Intelligent Door Sensor - Two active dry contacts powered by 12V to support 3rd party door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors- (2) 4 meter lock connector cables included.
