Adder ALDV100T Overview
When combined with the separately available DV100R receiver, the Adder ADDERLink DV100 HDMI Transmitter can send an SD or HD HDMI signal up to 164′ over standard Category (CatX) cable without any signal degradation. This solution works particularly well with computers, as the DV100T takes power from a standard USB Type-A port and transfers power to the DV100 receiver. Multichannel audio, HDCP, and EDID information are passed through, so you can watch protected HD content from Blu-ray players or other devices.
The ALDV100T is the transmitter unit. The full system with both receiver and transmitter units is the ALDV100P.
The ADDERLink DV100 Transmitter and Receiver
The ALDV100T is suitable for a wide range of applications, especially for the Digital Signage (DOOH – Digital Out-Of-Home) and Audio Visual (AV) industries.
AdderLink DV100T Video Extender Diagram
ADDER ALDV100T Features:
- Pixel perfect digital video up to 1080p or 1920×1200 @ 60Hz
- Digital audio support up to eight channels
- Seamless interconnectivity: HDMI transmitters (ALDV100T) can be connected to DVI-D receivers (ALDV100T) and vice versa.
- Extend video up to 50 meters over a single CATx cable
- Highly energy efficient – No external power supplies required
- Intelligent EDID management
- Plug and Play – no need to wait for drivers or software to be installed
- Perfect video wall companion – locking connectors are ideal for public environments
