DKX4-UST
Contact for Price
Ultra high performance User Station provides access to 4K servers, up to 3 monitors and 3X higher performance
| Brand | Raritan |
|---|
Part number: DKX4-UST
Description
Ultra high performance User Station provides access to 4K servers, up to 3 monitors and 3X higher performance
Technical Specifications
| Product Category | Enterprise IP KVM Switch |
| Server Port Options | 8, 16, 32, or 64 ports (model-dependent) |
| Simultaneous Remote Users | 1, 2, 4, or 8 (model-dependent) |
| Local Access Port | 1 digital local port (DVI-D) |
| Video Resolution | Up to 1920×1200 or 1080p at 30 fps |
| Supported Video Inputs | DVI, HDMI, DisplayPort, USB-C (digital); VGA (analogue) |
| Remote Access | LAN, WAN, Internet, mobile, dial-up |
| Dual Ethernet | Yes — dual 10/100/1000 Gigabit Ethernet with automatic failover |
| IPv4/IPv6 | Dual-stack IPv4 and IPv6 |
| Encryption | AES with FIPS 140-2 certified cryptographic module |
| Authentication | Two-factor, IEEE 802.1X, SmartCard/CAC, PKI certificates, RSA SecurID |
| Dual Power | Yes — dual power supplies with automatic failover |
| Virtual Media | Yes — Java-free |
| Mouse Technology | Absolute Mouse Synchronisation |
| Audio | Supported on KVM clients |
| Operating Temperature | 0°C – 45°C (32°F – 113°F) |
| Operating Humidity | 0% – 85% RH |
| Form Factor | 1U or 2U rack-mountable |
Source: Raritan — Dominion KX III / KX IV. Verify specifications with manufacturer before purchase.
