Description
Smart Lock Key Pad 1
Technical Specifications
| Product Category | Electronic Door Access and Control System |
| System Type | Networked intelligent electronic door access and control |
| Cabinet Coverage | Up to 16 cabinets (32 locks) per controller |
| Authentication Methods | Smart card (single and dual-frequency), PIN + card, two-factor authentication (2FA) |
| Reader Types | Basic, Standard LF reader, Standard HF reader, Dual-frequency HF reader |
| Handle Types | Southco, EMKA, or DIRAK electronic swinghandles |
| Audit Trail | Automated audit-trail logging of all access events |
| Access Control | User and group-level permissions with on-demand door control |
| Network Integration | IP-based; connects to Sensor Port on SRC or PX intelligent PDU |
| Power | Powered via SRC or PX — no separate power supply required |
| DCIM Integration | Compatible with Power IQ and other DCIM/security management platforms |
| Technology Platform | Raritan Xerus Technology Platform |
| Compliance Standards | PCI DSS, SOX, SSAE, HIPAA, GDPR, EN50600 |
| Installation | Retrofits existing cabinets — no inter-unit wiring required |
Source: Raritan — SmartLock. Verify specifications with manufacturer before purchase.
Shipping & Delivery
Related products
SML-KIT-SCO-60-2D
(2) H3-EM-60-100 Electronic Swinghandle - High security DIN lock - (1) DX2-DH2C2 Intelligent Door Sensor - Two active dry contacts powered by 12V to support 3rd party door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors- (2) 4 meter lock connector cables included.
SML-KIT-SCO-66-2D
(2)Electronic Handles H3-EM-66-100 - 13.56 MHz MIFARE? Classic 4k MIFARE Plus? 2k MIFARE? DESFire? 4k & iClass UID/integrated card reader: supports ISO14443 A [13,56 MHz] card types - Wiegand Output protocol - 4 pin reader connector - (1) DX2-DH2C2 Intelligent Door Sensor with Two active dry contacts powered by 12V to support (2) door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors - (2) 4 meter lock connector cables included.
SML-KIT-SCO-68-2D
(2) H3-EM-68-100 Electronic Swinghandle and RFID Card Reader - 125 kHz Prox card reader - supports HID 125 kHz Prox card types - Wiegand Output protocol - 4 pin reader connector- High security DIN lock (1) DX2-DH2C2 Intelligent Door Sensor - Two active dry contacts powered by 12V to support 3rd party door locks. Two digital Normally Closed (NC) or Normally Open (NO) contact closures that require customer-provided NC or NO switches, e.g. door open/closed, smoke present/absent, etc. Each of the two ports (channels) can be independently set to NC or NO, factory default is NC. Dual RJ-45 connectors- (2) 4 meter lock connector cables included.
