AdderView Rack Tray, 19" LCD integrated AVX1016 KVM Switch and CATx extender (RD1916)

AdderView RackDrawer 19″ Screen, Integrated 16 port CatX1000 KVM Switch XX Keyboard

The ADDERView RDX 1000 series provides local and remote management for your server room with an integrated Adder AVX1016 KVM Switch and CATx extender. This unit features a 19 inch premium quality Samsung SXGA 1280 x1024 TFT LCD panel with touchpad control and advanced OSD for device selection. This product can control 16 computers and expands up to 256 computers by adding CATx 1000 switches. The 1U keyboard tray is available in most language layouts as well. The RDX 1000 can be controlled by a user from up to 300m away, over CATx cable using the integrated CATx extender and an ADDERLink X200 or X100 receiver. The integrated RS232 gives the ability to control other external devices such as power management devices. The RDX 1000 provides exceptional high video performance up to 1920 x 1200 resolutions. In addition, DDC emulation and continuous keyboard and mouse emulation is further enhanced by DC balancing to ensure full, true color and faultless operation across your unique installation. This unit provides country code reporting as well and is available with the following connectivity options: Serial (AVX5000 only), USB, PS/2, VGA & 3.5mm Audio.

Adder RD1916-US Features:

• One local and one remote user (from up to 300m away over CATx cable using the optional ADDERLink X200 or X100 receiver)
• 1920 x 1200 resolution
• DDC emulation and faultess video quality
• DC balancing
• Integrated CATx extender
• Locking power supply
• True multi-platform capability and connectivity
• RS232 port

Technical Specifications

Source: Adder Technology — ADDERView RDX Rack Drawer. Verify with manufacturer.
