Adder XD641 Overview
The AdderLink XD Standard Single 4K Displayport Extender Pair with USA Mains Cables from Adder is a high-performance KVMA (Keyboard, Video, Mouse, and Audio) extender that is designed to provide reliable and real-time access to critical computers, regardless of the location, whilst maintaining the same user desktop experience. Developed for enterprise organizations and high-pressure control rooms, it combines the simplicity of true plug and play and high-performance HD KVM extension, resulting in superior functionality and flexibility in a cost-effective, reliable, and straightforward solution.
The ADDERLink XD641 is a high-performance KVMA (Keyboard, Video, Mouse, and Audio) extender that is created to provide reliable and real-time access to crucial computers – regardless of the location while maintaining the same user desktop experience.
Produced for enterprise organizations and high-pressure control rooms, it combines the simplicity of true plug-and-play and high-performance 4K KVM extension, resulting in superior functionality and flexibility in a cost-effective, reliable and straightforward solution.
- Single-head 4K60 video, USB2.0 and audio via single CATx or Fiber cable
- Point-to-point protocol for ultra-low latency
- Flexibility between copper and fiber connectivity
- Adder’s USB emulation ensures reliable computer bootup
AdderLink XD extender modules provide support for:
- High quality digital video
- Video resolutions up to 4K 4096 x 2160 @60Hz
- USB keyboard and mouse plus two other USB devices (up to USB 2.0)
- RS232 can be passed between the units to a maximum baud rate 115K2 with RTS/CTS flow control
- HD audio quality (stereo audio, 24-bit sampled at 96kHz) for line in/out, microphone and headphone speakers
ADDERLink XD641 Features
-
-
High-resolution video, real-time control
The system supports resolutions up to 4096×2160 @ 60Hz using 8 bits per color and 4:4:4 chroma sampling.
-
Single cable
Video, audio, USB HID (human interface device), hi-speed transparent USB and RS232 signals are transmitted over a single CATx or fiber cable.
-
Up to 4km/2.5 mile extension distances
The ADDERLink XD641 supports both copper and fiber interfaces. It provides a range of up to 100m over a CAT6 cable link, and up to 4km over an optical fiber link.
-
-
-
Emulated USB2.0
Enables connection of any full and low speed USB HID from mouse and keyboards through to graphics tablets and joysticks.
-
EDID management
The system has intelligent EDID management to allow the true characteristics of the monitor to be passed back to the computer.
-
Plug and Play
The ADDERLink XD641 extender is delivered in a zero config. state so it works, without the need for drivers or software, as soon as it is connected.
-
-
Digital audio
Video: Encapsulates eight channels of 24-bit, 192kHz sampled “Pulse-code modulation” (PCM) uncompressed audio integrated with video signal. USB: Two channels of 24-bit, 96kHz sampled PCM audio.
-
HD quality analog audio
HD audio quality (stereo audio, 24-bit sampled at 96kHz) is available for line in/out, microphone and headphone or speakers.
-
Serial communications
RS232 can be passed between the units to a maximum baud rate 115K2 with RTS/CTS flow control.
