Adder ADDERLink X2 Series Silver - VGA, PS/2, RS232 Extender Pair to 300 Meters (X2-SILVER/P)
Contact for Price
The ADDERLink X2-Silver, (part of the ADDERLink X Series range), extends very high quality video, keyboard, mouse and transparent, high speed RS232 up to 200m (650ft) over Category 5 or higher UTP cable. The ADDERLink X2-Silver has been designed to provide industry-leading video clarity, compatibility and high rack densities.
Dual access versions provide local KVM access at the computer for local as well as remote control.
| Brand | Adder |
|---|
Part number: X2-SILVER/P
Description
The AdderLink X2-Silver extends high quality video, keyboard, mouse and transparent RS232 up to 300m/1000ft over Category 5 or higher cable. The X2-Silver-P achieves resolutions of 1600 x 1200 at 200m/650ft and 1280×1024 at 300m/1000ft. Integral electronic DeSkew is also provided with this CAT5 extender to compensate for any color skew effects that may be introduced by long CATx cables, achieving crystal clear video, even at longer distances. For maximum convenience all video adjustments may be simply made using the keyboard.
DDC circuits are also fitted to enable the computer to query the monitor so that the video card can be optimally configured. Without this circuitry, some well known high performance video cards cannot be used at high resolutions. All X2 extenders feature transparent serial ports that enable a wide range of serial devices to be connected at baud rates up to 57,600.
AdderLink X2-Silver KVM Extender Diagram
Adder X2-Silver-P Features
- Extends KVM and transparent RS232 across a single CATx cable
- Video quality at resolutions up to 1600 x 1200 at 200m and 1280 x 1024 at 300m
- Fully transparent RS232 interface enables a wide range of serial devices to be connected
- Integrated state of the art 300MHz DeSkew circuit (up to 62ns DeSkew with 2ns granularity)
- Use stand alone or rackmount 16 modules across 2U
- Advanced spike suppression circuits for reliability in noisy applications
- Flash upgradeability enables future enhancements
- Supports DDC signaling to ensure optimal video card setup
Adder X2-SILVER Receiver Front & Back View
Technical Specifications
| Video | VGA (HDD15) |
| Maximum Resolution | 1600 x 1200 to 200m/650ft; 1280 x 1024 to 300m/1000ft |
| Extension Distance | Up to 300m/1000ft over CATx (CAT5 or higher) |
| Keyboard/Mouse | PS/2 |
| Serial | RS232 (transparent, high speed) |
| Skew Compensation | 300MHz bandwidth skew correction |
| Operating Temperature | 0–40°C (32–104°F) |
| Power Supply | 100–240 VAC 50/60Hz, 5V DC 500mA |
| Dimensions | 172mm W × 26mm H × 75mm D, 430g |
| Rack Mount | Up to 16 units in 2U chassis |
| Certifications | CE, FCC |
| OS Support | All known operating systems |
Source: Adder Technology — ADDERLink X2-Silver. Verify with manufacturer.
