Adder AV extender receiver with SKEW Compensation (ALAV101R)

The AdderLink AV Series ALAV101R receiver with integrated skew compensation delivers high video resolutions and quality audio up to 300m/1000 feet using standard CATx cable (x=5,5e,6,7). Designed for use in Digital Signage applications, the design of this extender allows for flexible distribution that can grow in line with project developments and ensures direct delivery of crystal clear communication to consumers at the point of decision.

Adder AV-Series KVM Extender System Diagram

Adder ALAV101R Features

• Duplicates input from transmitter allowing for 2 video and 2 audio outputs
• Integrated skew adjustment allowing the receiver to be located further from the transmitter and/or cope with higher video resolutions
• Can be used as a receiver up to 300m from AdderLink AV 100T or AdderLink AV 104T transmitters
• Has local cascade port allowing for other receivers to be cascaded from the original receiver
• Extends video and audio across a single CATx cable
• Extra fine video quality at resolutions up to 1600 x 1200 at 200m and 1280 x 1024 at 300m
• High fidelity click less digital audio (16bit, 44.1 kHz, stereo)
• Independent sharpness and brightness control
• DDC support
• Feed through / cascade port at transmitter
• Dual video and audio outputs at receiver
• Use stand alone or rack mount 16 modules across 3U
• Advanced spike suppression circuits for reliability in ‘noisy’ installations
• All metal construction
• Power / video indication confirm correct operation
• Adjustable cable equalization amplifiers
• Audio transmitted as digital signals to ensure high fidelity and low noise levels

Technical Specifications

Source: Adder Technology — ADDERLink AV100. Verify with manufacturer.
