C-USB LAN USB2.0 extender over GbE LAN Pair with UK mains lead (C-USB-LAN-P)
ADDER® C-USB LAN — USB 2.0 over Gigabit Ethernet extender. Transparently extends any USB device up to 100m over CAT5e, or across any 1GbE IP network. Supports HID, mass storage, webcams, headsets, graphics tablets and other isochronous USB devices.
| Brand | Adder |
|---|
Part number: C-USB-LAN-P
ADDER® C-USB LAN — High-performance USB 2.0 extender enabling remote placement of computing hardware while maintaining the original user desktop experience. Transmits USB 2.0 over single CATx cables or 1GbE IP networks.
Comprehensive USB 2.0 Device Support
Supports any USB device including mice, keyboards, touch screens, graphics tablets, jog shuttles, joysticks, 3D explorers, mass storage devices, webcams, headsets and microphones.
Transparent USB Operation
Operates transparently to the host computer and peripherals — devices function as if directly connected to the host, with no perceptible performance degradation.
Network Flexibility
Works over a single CAT5e or better cable up to 100m, or across any Gigabit Ethernet IP network. Paired units auto-synchronise and locate each other over the network — zero configuration required.
Integrated AIM Control
Controllable via AdderLink INFINITY Manager (AIM). Can be programmed for tandem or independent switching alongside AdderLink Infinity units for unified access control.
Open API
Open API available for authorised third-party control system integration, enabling seamless embedding into custom workflows and AV/IT management platforms.
Technical Specifications
| USB | USB 2.0 (compatible with USB 1.1; USB 3.0 in USB 2.0 mode at 480Mbps) |
| USB Ports | 4 USB ports (connect up to 4 peripherals) |
| Network | 1GbE (IP LAN) or CATx direct cable |
| Extension Distance | Up to 100m/328ft over single CATx |
| Device Support | Mice, keyboards, touch screens, tablets, webcams, headsets, mass storage |
| Isochronous Devices | Yes — webcams, headsets, microphones |
| Configuration | Zero config, plug and play; no drivers required |
| AIM Integration | ADDERLink INFINITY Manager (AIM) compatible |
| API | Open API for third-party control systems |
| OS Support | All known operating systems |
Source: Adder Technology — ADDER C-USB LAN. Verify with manufacturer.
