PX3-3272-M11Q1 3PH, 380-415V, 32A, 2 lines, 1RU, Residual Current Monitor
Contact for Price
3PH, 380-415V, 32A, 2 lines, 1RU, Residual Current Monitor
| Brand | Raritan |
|---|
Part number: PX3-3272-M11Q1
Description
The Raritan PX3 is a 3rd-generation intelligent rack PDU that delivers reliable, metered power distribution for data centre cabinets. The PX3 series offers per-inlet, per-outlet, and per-breaker metering with ±1% accuracy, remote outlet switching, environmental sensor support, and a full-colour LCD display. Networking is via Gigabit Ethernet with support for SNMP, HTTPS, SSH, Modbus-TCP, and JSON-RPC API. Multiple PDUs can be linked (up to 8) or cascaded (up to 32) to share a single IP address.
Specifications
| Phase | Three-phase |
| Input Voltage | 380–415V |
| Input Current | 32A |
| Form Factor | 1U horizontal |
| PDU Lines / Breakers | 2 lines |
| Onboard Display | Colour matrix LCD |
| Outlets | IEC C13 and C19 outlets |
| Energy Metering | Voltage, Current, Active Power (kW), Apparent Power (kVA), Energy (kWh), Power Factor |
| Metering Accuracy | ISO/IEC 62053-21 ±1% |
| Metering Level | Per input line, per branch circuit breaker, per outlet |
| Remote Outlet Switching | Yes |
| Environmental Sensor Support | Temperature, Humidity, Airflow, Differential Pressure, Water Leak, Contact Closure |
| Networking | 10/100/1000 Base-T Ethernet (primary + secondary redundant), optional Wi-Fi 802.11 a/b/g/n |
| Remote Management | HTTPS, SSH (CLI), Telnet, RS-232, SNMP v2/v3, SMTP, JSON-RPC API, Modbus-TCP, Redfish API |
| PDU Linking | Up to 8 PDUs per group via PDU Link Port |
| Cascading | Up to 32 PDUs per Ethernet port |
| Replaceable Controller | Yes, hot-swappable |
| Operating Temperature | 0–60°C |
| Operating Humidity | 5–95% RH non-condensing |
| Residual Current Monitoring | Yes — monitors leakage current per outlet for safety and compliance |
Source: Raritan
