RARITAN PX3TS-1875R | TRANSFER SWITCH | 200-240V | 2X16AMP C20 | 1U | 1 X C19 | 4-8MS TRANSFER

⚠ End-of-life product. This product has been discontinued. Contact us for a replacement recommendation.
Contact for Price

Raritan, Transfer Switch, ATS, 1PH, 230V AC, 16A (16A rated); 9 outlets: 8x C13, 1x C19; plug: IEC 60309 2P+E 6h 16A (Rear feed), 3.7kVA; Unit Metered, 1U horizontal transfer switch, SecureLock ready, LCD display, Ethernet, serial, 2x USB-A, USB-B and sensor connections

Brand

Part number: PX3TS-1875R

SKU: PX3TS-1875R Category: Tags: , ,
Description
General Information
CategoryPower distribution units PDUs
DescriptionRaritan Intelligent Rack Transfer Switch PX3TS-1875R – Power control unit (rack-mountable) – Ethernet, RS-232, USB – input: IEC 60309 16A – output connectors: 9 – 1U
ManufacturerLegrand
MSRP$1,994.00
UNSPSC39121017
Main Specifications
General / SubcategoryPower distribution devices
Header / BrandRaritan
Miscellaneous / Product ColorBlack
Networking / Remote Management Interface
  • Ethernet
  • RS-232
  • USB
Packaged Quantity1
Power Device / Form FactorRack-mountable
Power Device / Output Connector Qty9
Product TypePower control unit
Environmental Parameters
Humidity Range Operating0 – 85% (non-condensing)
Max Operating Temperature60 °C
Expansion / Connectivity
Interfaces
  • 1 x management (Ethernet) – RJ-45
  • 1 x management – 9 pin D-Sub (DB-9)
  • 1 x management – 4 pin USB Type A
  • 1 x modem – 9 pin D-Sub (DB-9)
  • 1 x monitoring – RJ-12
  • 1 x USB – 4 pin USB Type A
  • 1 x USB – 4 pin USB Type B
  • 1 x KVM – RJ-45
General
Device TypePower control unit – rack-mountable
Height (Rack Units)1U
Miscellaneous
FeaturesLED display
Networking
Remote Management InterfaceEthernet, RS-232, USB
Remote Management ProtocolSNMP
Power Device
Circuit ProtectionFuse
Input Connectors2 x power IEC 60309 16A
Input Voltage RangeAC 200 – 240 V
Max Electric Current16 A
Output VoltageAC 200-240 V
Power Consumption Operational20 Watt
Power Output Connectors Details
  • 8 x power IEC 60320 C13
  • 1 x power IEC 60320 C19

Technical Specifications

Product CategoryIntelligent Rack PDU
PX3 ProcessorARM9 400 MHz (Atmel SAM9G20)
PX3 Flash Memory16MB NOR Flash
PX3 RAM64MB SDRAM
PX3 DisplayHigh-Resolution Colour TFT (220 x 176)
PX2 Display7-Segment LED Display
CascadingUSB cascading, up to 16 devices
Hot Swap ControllerYes (PX3); No (PX2)
Input Voltage Range100V single phase to 480V three phase
Input Current Range12A up to 100A per line
Max Input CapacityUp to 67 kVA
Max Outlet DensityUp to 60 outlets per chassis
Input Cord LengthStandard 3 m (10 ft); optional custom up to 10 m
Metering Accuracy±1% (ISO/IEC 62053-21 / EU2014/32 MID compliant)
Metered ParameterskWh, Voltage (V), Current (A), Active Power (kW), Apparent Power (kVA), Energy (kWh), Power Factor
Remote Outlet SwitchingYes — configurable power sequencing, load shedding, last-known-state power-on
Networking10/100 BaseT Ethernet; optional Gigabit Ethernet; WiFi 802.11a/b/g/n
Management ProtocolsHTTP(S), SSH CLI, Telnet, RS-232, SNMP v2/v3, SMTP, IPv6/IPv4, Modbus/TCP
AuthenticationLDAP, Active Directory, RADIUS, local credential database
Environmental Sensor CapacityUp to 32 plug-and-play sensors per PDU
Sensor TypesTemperature, humidity, airflow, differential pressure, water leak, contact closure
Operating TemperatureUp to 60°C (140°F) maximum ambient
Operating HumidityUp to 85% relative humidity
Form Factors0U vertical, 1U horizontal, 2U horizontal
WarrantyStandard 2 years; optional up to 5 years
CertificationsUL, Canada ICES-003, FCC Part 15 Class A, RoHS, CE, SAA, EAC

Source: Raritan — Intelligent Rack PDUs. Verify specifications with manufacturer before purchase.
