AdderLink X200 USB KVM & Audio Remote User Station Inc SKEW Compensation (X200AS/R)
Contact for Price
ADDERLink X200s have been designed for use in applications where up to two computers can have their keyboard, video, audio and mouse control extended up to 200m (650 ft.) across CAT5 or higher UTP cable.
Key Features
- Pairs with Optional CAM Modules
- Control up to 2 Computers
- Extend Keyboard, Mouse, VGA Video, Audio
- VGA, 3.5mm Audio, 2 USB & 2 RJ45 Ports
- 1600 x 1200 Supported VGA Resolution
- Integrated De-Skew
- Video Compensation
- Brightness Control
| Brand | Adder |
|---|
Part number: X200AS/R
Description
The Adder X200AS/R is a X200 user station for CATx switches that includes VGA, USB, audio and DeSkew with built-in 2-port KVM switch.
It’s a Hi Resolution VGA, USB keyboard and Mouse plus stereo audio CATx Extender. It support two remote computers up to 300 Meters. It is a fully featured USB keyboard, video and mouse extender with 44.1kHz digital stereo audio support for two computers.
AdderLink X200s have been designed for use in applications where up to two computers can have their keyboard, video, audio and mouse control extended up to 300 m (1000 ft.) across CAT5 or higher UTP cable. The AdderLink X200 provides absolute real time keyboard and mouse performance along with hi-definition, hi-resolution video over a VGA interface. The AdderLink X200 receiver can also be used as a remote user station for the AdderView CATx range of KVM switches.
Adder X200AS/R-US Diagram
- Compact USB KVM extender receiver, up to 1000 ft (300 m)
- Transparent USB, VGA video and stereo audio over single CATx wire
- High video quality up to 1920 x 1200
- Integrated De-Skew correction
- Finely adjustable video compensation
- CD quality stereo audio
- 2-Port integrated KVM switch
- 2-port USB 2.0 hub at receiver
Adder X200AS/R Receiver Front & Back View
Technical Specifications
| Video | VGA (HDD15); 1600 x 1200 to 200m/650ft; 1920 x 1200 to 50m/165ft |
| Extension Distance | Up to 200m/650ft over CATx (CAT5 or higher) |
| USB | USB keyboard and mouse |
| Audio | 44.1kHz digital stereo (optional, 3.5mm jack) |
| Skew Compensation | AS/R model: 300MHz bandwidth, 1/4 pixel at 1600×1200 |
| Built-in KVM Switch | 2-port integrated switch (control 2 computers) |
| Remote Connections (RX) | 2x RJ45, for 2 computer connections |
| Operating Temperature | 0–40°C (32–104°F) |
| Power Supply | 100–240 VAC 50/60Hz (remote unit only) |
| Dimensions (RX) | 172mm W × 26mm H × 75mm D, 430g |
| Dimensions (TX) | 64mm W × 45mm H × 25mm D |
| Certifications | CE, FCC |
| OS Support | Windows, DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare |
Source: Adder Technology — ADDERLink X200. Verify with manufacturer.
