AdderView Matrix C1100 User Station (AVM-C1100-USR)
Contact for Price
ADDERView Matrix is the perfect solution for any organization looking for a simple and powerful IP KVM matrix. Broadcast Studios Where the system is self-contained, and no additional security protocols are required beyond physical access to the studio – ADDERView Matrix is a perfect solution. ADDERView Matrix delivers pixel-perfect, color-accurate video without artifacts using spatially lossless 1:1 pixel encoding. Space Constrained Control Rooms Outside broadcast trucks, ship control rooms or s
| Brand | Adder |
|---|
Part number: AVM-C1100-USR
Description
ADDERView Matrix is the perfect solution for any organization looking for a simple and powerful IP KVM matrix.
Broadcast Studios
Where the system is self-contained, and no additional security protocols are required beyond physical access to the studio – ADDERView Matrix is a perfect solution. ADDERView Matrix delivers pixel-perfect, color-accurate video without artifacts using spatially lossless 1:1 pixel encoding.
Space Constrained Control Rooms
Outside broadcast trucks, ship control rooms or security control rooms, are typically places where space is at a premium and a simple-to-install IP KVM solution is a perfect fit. An ADDERView Matrix can be installed without occupying extra rack space or resources using ZeroU™ USB-powered modules.
Industrial Remote Access Control
Many industrial processes where an operator controls and monitors multiple systems will benefit from increased productivity with ADDERView Matrix. With ADDERView Matrix, accessing remote areas of industrial complexes is easy. Extension distance is unlimited — just add fiber optic transceivers via the built-in SFP port to extend beyond 100 meters.
Technical Specifications
| Video | DisplayPort 1.1 (dual mode) |
| Maximum Resolution | 2560 x 1600 @ 60Hz |
| Colour Depth | 8 bpc |
| USB | 4x USB 2.0 True Emulation (full/low/high speed) |
| Network | 1x RJ45 (8p8c), 1x SFP cage, 1GbE |
| Extension Distance | Up to 100m/328ft (CAT5e and above) |
| Audio | Analog/Digital 2-channel, 16-bit / 48kHz, bi-directional |
| Audio Connectors | 1x 3.5mm input, 1x 3.5mm output |
| Operating Temperature | 0–40°C (32–104°F) |
| Humidity | 10–90% (non-condensing) |
| Power Supply | 12V 3-pin external PSU, max 18W, typical 7W, fanless |
| Dimensions | 186mm W × 39mm H × 150mm D |
| Weight | 1.1kg (2.4lb) |
| MTBF | 340,000 hours (Telcordia SR332) |
| Certifications | CE, cULus, FCC, ICES, KC, RCM, UKCA |
| OS Support | All known operating systems |
Source: Adder Technology — ADDERView Matrix C1100 User Station. Verify with manufacturer.
