Technical Specifications
| Product Type | Fingerprint Recognition Module (CosmicConnect IP KVM Matrix) |
| Power | 5V, 70mA |
| Operating Mode | Optical |
| Image Input Time | <0.5 seconds |
| Collection Window | 20mm x 32mm |
| Effective Image Area | 12mm x 15mm |
| Resolution | 256×288 pixels at 500 DPI |
| False Acceptance Rate (FAR) | <0.001% |
| False Rejection Rate (FRR) | <0.005% |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +80°C |
| Dimensions | 50mm x 60mm x 78mm |
Source: DSGIO — CC-FP CosmicConnect Fingerprint Login System. Verify with manufacturer.
