UFF-CCF10G-XXXM (Data + Video + PD)
Contact for Price
USB 3.2 Gen 2×1 Adaptive 2 or 4 Lanes Type C Full Featured AOC offering Data 10G + Video 4K + PD 60W, Backward Compatible.
| Brand | DSGIO |
|---|
Part number: UFF-CCF10G-XXXM
Description
Technical Specifications
| Cable Type | USB-C Active Optical Cable (Data + Video + PD) |
| Available Lengths | 5m, 8m, 10m, 15m |
| Connector | USB Type-C Male (both ends); Zinc Alloy |
| Data Transfer Rate | 10Gbps per direction; 20Gbps bidirectional |
| Video (Mode 1) | 4-lane DisplayPort 2.1 with USB 2.0 |
| Video (Mode 2) | 2-lane DisplayPort 1.4 with USB 3.2 (10Gbps) |
| Video Resolution | 4K@60Hz or 8K@30Hz via DisplayPort Alt Mode |
| Power Delivery (5m-10m) | 60W (20V/3A) |
| Power Delivery (over 10m) | 40W |
| Backward Compatibility | USB 2.0 and 1.1 |
| Cable Diameter | 6.5mm |
| Construction | 5 fiber strands + 12 copper wires; PVC jacket |
| EMI/RFI Resistance | Yes |
| Installation | Plug-and-play, driver-free |
Source: DSGIO — UFF-CCF10G-XXXM (Data + Video + PD). Verify with manufacturer.
Source: DSGIO — UFF-CCF10G-XXXM (Data + Video + PD). Verify with manufacturer.
