ADDERView 4 port DPHDMI to HDMI multi-viewer switch (CCS-MV4224)
Contact for Price
ADDERView® CCS-MV 4224 Multi-Viewer – CCS-MV4224 – Command and control multi-viewer switch for sharing 4K video, keyboard and mouse, plus audio between four computers. Innovative hybrid DisplayPort™ and HDMI® input ports for flexible connectivity from a single computer.
| Brand | Adder |
|---|
Part number: CCS-MV4224
SKU:
CCS-MV4224
Categories: KM Switches, KVM Switches
Description
ADDERView® CCS-MV 4224 Multi-Viewer – CCS-MV4224 – Command and control multi-viewer switch for sharing 4K video, keyboard and mouse, plus audio between four computers. Innovative hybrid DisplayPort™ and HDMI® input ports for flexible connectivity from a single computer.
Technical Specifications
| Video Inputs | 4x hybrid DisplayPort 1.2 / HDMI (dual-mode) |
| Video Outputs | 1x hybrid DisplayPort 1.2 / HDMI (dual-mode) |
| Maximum Resolution | 3840 x 2160 (UHD 4K) @ 30fps |
| Colour Depth | 8 bpc |
| Computer Ports | 4 |
| USB (Computer) | 4x USB 2.0 HID True Emulation; 4x USB 2.0 High Speed |
| USB (Console) | 2x USB 2.0 HID; 1x USB 2.0 High Speed |
| Audio | Analog/Digital 2-channel, output only, 3.5mm jack |
| Switching | Mouse-across-screen; hotkey; front-panel |
| Operating Temperature | 0–40°C (32–104°F) |
| Certifications | CE, cTUVus, FCC, ICES, UKCA |
| Compliance | Cal Prop 65, China RoHS, EU REACH, UK REACH |
| Warranty | 2 years |
Source: Adder Technology — ADDERView CCS-MV 4224. Verify with manufacturer.
