Audio-Transceiver-Fiber(M) - ANALOG (A1990032)
Contact for Price
Transmission system (transceiver) for analog audio signals (no digital audio) Product variants Audio-Transceiver-Fiber(M) Audio-Transceiver-Fiber(M) – ANALOG
| Brand | Guntermann & Drunck |
|---|
Part number: Audio-Transceiver-Fiber(M) - ANALOG
Description
Product Details
Signals
- Amplifiable input signal for microphones etc.
- Bidirectional audio signals in stereo/CD quality
Transmission
- The transmission distance is up to 550 meters over fiber multimode optics, incl. transmission module(s)/SFP transceiver(s)
Device
- External power supply
Warranty
- A 3-year, free of charge product guarantee
- For an additional fee guarantee extension possible
Technical Specifications
| General | |
|---|---|
| Brand | G&D |
| Product group | KVM extenders |
| Product Family | Audio-Transceiver |
| Country of origin | Germany |
| Number of sources | 1 |
| Power Supply | no redundancy |
| Transmission | |
| Number of transmission channels | 1 |
| Redundant transmission channels | no redundant KVM transmission |
| Range | 250 m (50.0/125µm, OM2) 550 m (62.5/125µm, OM1) 550 m (50.0/125µm, OM3) 550 m (50.0/125µm, OM4) |
| Laser class | Class 1 |
| Type of interface | LC-Duplex |
| Wavelength | 850 nm |
| Medium | Fiber MM |
| Data rate | 1 Gbit/s |
| Audio | |
| Transmission type | Bidirectional Stereo |
| Resolutions | 24 bit digital |
| Sampling rate | up to 192 kHz |
| Bandwidth | 22 kHz |
| Audio support | Analog |
| Maintenance | |
| Update via | Update Wizard (service interface) |
| Serviceport settings | 115200bps (8/N/1) |
| Housing | |
| Material | Anodised aluminium |
| Active cooling (fan) | no |
| Width ca. | 105 mm |
| Height ca. | 26 mm |
| Depth ca. | 84 mm |
| IP protection class | IP20 |
| Weight ca. | 0.22 kg |
| Operating conditions | |
| Operating environment temperature | 5 °C to 45 °C |
| Operating air humidity, non-condensing | 20 % to 80 % |
| Area of application | Indoor use |
| Maximum operating altitude above sea level | 3,048 m |
| Storage environment temperature | -10 °C to 55 °C |
| Storage air humidity, non-condensing | 15 % to 80 % |
| MTBF | 300,000 h at 25°C |
| Conformities | CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads) |
| Power supply | |
| Quantity | 1 |
| Type | External |
| Input voltage | 12 VDC |
| Current consumption | 0.3 A |
| Power consumption idle | 1.87 W |
| Power consumption max. | 1.99 W |
| Heat output idle | 1.87 W |
| Heat output max. | 1.99 W |
Source: G&D — Audio-Transceiver-Fiber(M) – ANALOG (A1990032). Verify with manufacturer.
