Adder ADDERLink X50 - VGA, USB, Audio to 50 Meters Over Single CATx with Local Control and 4-Port USB H (X50)
Contact for Price
AdderLink X50. Transparent USB & VGA KVMA CATx Extender 50 Mtr
| Brand | Adder |
|---|
Part number: X50
Description
AdderLink X50. Transparent USB & VGA KVMA CATx Extender 50 Mtr
Technical Specifications
| Video | VGA (HDD15) |
| Maximum Resolution | 1920 x 1200 @ 60Hz |
| Extension Distance | Up to 50m/150ft over CATx (CAT5 or higher) |
| USB | USB 1.1/2.0 Low and Full speed; integrated 4-port hub |
| Audio | CD-quality 44.1kHz stereo, digital, 3.5mm jack |
| DDC | True DDC emulation; full 2-page DDC |
| Operating Temperature | 0–40°C (32–104°F) |
| Power Supply | 100–240 VAC 50/60Hz, 10W (remote unit only) |
| Dimensions | 120mm W × 26mm H × 75mm D (both units) |
| Weight | 430g per unit |
| Certifications | CE, FCC |
| OS Support | Windows, DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare |
Source: Adder Technology — ADDERLink X50. Verify with manufacturer.
