Name: TradeSwitch8-USB (A2100118) - eNOVA Technologies
Brand: Guntermann & Drunck
SKU: TradeSwitch8-USB
Price: 1.00 SGD
Availability: BackOrder

TradeSwitch8-USB (A2100118)

Contact for Price

Keyboard/mouse switch to operate up to 8 computers over one set of keyboard and mouse

Part number: TradeSwitch8-USB

Product Details

Video

The TradeSwitch does not process video signals. Each monitor of the user console is directly connected to the computer and permanently displays its image.

Signals

Stereo audio signals

USB 2.0 with hi-speed, all USB classes

Device

Accesses as hardware switch only the standard interfaces keyboard, mouse and audio

Access to standard interfaces of the computer, with no software installation required

Internal power pack for main power supply

System update

Flash upgrade via the device

Warranty

A 3-year, free of charge product guarantee
For an additional fee guarantee extension possible

Features

Operation features

With the TradeSwitch, you can operate several computers over only one set of keyboard/mouse.

Switching between computers is done either via the buttons on the front of the TradeSwitch, via configurable key combinations on the keyboard or via a serial device.

Ready for operation out of the box, no additional configuration required

Permanent keyboard/mouse emulation ensures a stable system

Control options

CrossDisplay-Switching: The mouse acts as if on a “virtual desktop” and can be moved seamlessly across the connected displays. Moving the cursor from the active to another display, the keyboard-mouse focus automatically switches to the connected computer. This feature lets you create multi-monitor workplaces, where users do not have to deal with the actual infrastructure. Thus, they are able to perform their tasks while operating the system intuitively. The mouse becomes the ultimate intuitive switching tool.

Extensions

Device

Attach the optional LED sets to the monitors. This facilitates locating the monitor (computer) to which the keyboard/mouse focus is switched to.

Technical Specifications

General
Brand	G&D
Product group	KVM switches
Product Family	TradeSwitch
Country of origin	Germany
Number of workstations	1
Number of sources	8
Power Supply	no redundancy
Input options
USB mouse	yes
USB keyboard	yes
Audio
Transmission type	Stereo
Bandwidth	22 kHz
Audio support	Analog
USB
Separate USB transmission port	no
Specification	USB 2.0
Transmission rate	max. 480 Mbit/s (Hi-Speed)
Range	max. 5 m
Power (output)	500 mA (HighPower)
USB classes	All
Maintenance
Update via	Update Wizard (service interface)
Serviceport settings	115200bps (8/N/1)
Housing
Material	Anodised aluminium
Active cooling (fan)	no
Width ca.	436 mm
Height ca.	44 mm
Depth ca.	210 mm
IP protection class	IP20
Weight ca.	2.1 kg
Operating conditions
Operating environment temperature	5 °C to 45 °C
Operating air humidity, non-condensing	20 % to 80 %
Area of application	Indoor use
Maximum operating altitude above sea level	3,048 m
Storage environment temperature	-10 °C to 55 °C
Storage air humidity, non-condensing	15 % to 85 %
MTBF	185,000 h at 25°C
Conformities	CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)
Power supply
Quantity	1
Type	Internal
Input voltage	100-240 VAC
Input frequency	60-50 Hz
Current consumption	0.2-0.1 A
Power consumption idle	2.9-3.7 W
Power consumption max.	11.2-11.6 W
Heat output idle	2.9-3.7 W
Heat output max.	5.2-5.6 W

Source: G&D — TradeSwitch8-USB (A2100118). Verify with manufacturer.
